8-16 Zone Fire Telephone Panel
This fire telephone panel is a new fire special communications equipment
AW-FTP2008 (8 zones), AW-FTP2016 (16 zones) fire telephone panel is a new fire special communications equipment, when the fire accident, which provides a convenient means of communication, the fire control and alarm systems necessary communications products. Wall-mounted structure is easy to install, suitable for small systems.
Features:
-
Wall-mounted structure is easy to install, suitable for small systems.
-
The device is composed of a star switchboard fire communications system. You need to connect an extension before the composition of the fire alarm communication systems. Extension is a dedicated co-electric fire telephone or regular telephone.
-
When the device goes off-hook extension audible alarm. When the extension with the switchboard call, the corresponding extension indicator light, stop the sound and light alarm.
-
The device can simultaneously call multiple extensions. Each extension can be inserted at any time or to exit.
-
The device uses a digital recording, reliable, durable and automatic recording for each call.
-
All keys are used on the device panel touch keys, feel good, beautiful, reliable and durable.
-
This equipment working conditions: temperature of 0 ~ 40 ℃, relative humidity 40% ~ 85%, no vibration.
Parameters:
Power Supply |
AC 220V 50Hz or DC 24V |
AC Current |
≤0.5A |
Extension loop resistance
(including telephone resistance) |
not more than 1000 Europe |
Frequency Range |
300 ~ 3400Hz (± 3 dB) |
Crosstalk level |
less than -60dB (600 ohm load) |
Transmission attenuation |
less than 5dB |
|
